|Directions For Deck Stairs Hand Rails|
Building Deck Steps Introduction
You need deck stairs and hand rails for your new deck. The stairs may seem daunting enough, but then there are hand rails too. The angles involved may seem like a serious challenge, but in reality they are quite simple to measure and cut. Your stairs need to be accurate–building inspectors take stairs quite seriously and you are not allowed to vary more than 1/4 inch in the height or depth of each step. Hand rails have to be a specific height, match the angle of the stairs and many local codes require a mitered return. Follow these instructions for DIY deck stairs and hand rails.
Measure the Total Rise from the top of the deck boards to the top of the landing. A comfortable step height for most people is between 6 1/2 and 7 1/2 inches. Divide the Total Rise by 7 1/2 inches and round the result up to find how many steps you need. Then divide the Total Rise by the number of steps to find the rise of each step.
|Measuring & Calculating Deck Stairs|
If the Total Rise is 48 inches, then 48 ÷ 7.5 = 6.4. Rounded up = seven steps. Now divide 48 by 7 steps to get 6.86 inches per step. We’ll make that 6 7/8 inches and adjust the bottom step 1/8 inch to make it up.
The tread length will be 11 inches, but allow for a 1-inch overhang on each step to give a 10 inch cut for the treads on the stringers. Since we have 7 steps, 7 x 10 inches = a total length of 70 inches.
Building Stair Stringers
Lay a 2-by-12 board on a pair of sawhorses and set a framing square on it. We’ll call the short leg the rise and the long leg the run. For our example stairs, the rise is 6 7/8 inches and the run is 10 inches. Align the 6 7/8 inch mark and the 10 inch mark on the square with the edge of the 2-by-12 and draw a line on both legs of the square. Repeat this to mark all the steps, but shorten the bottom riser height by tread thickness and any adjustment necessary. At the top, extend the top riser cut line all the way across the board and do the same at the bottom with the tread line that represents the landing.
|Cutting Deck Stair Stringers|
Cut the first stringer with a circular saw. First cut the two extended cut lines at the top and bottom. Then cut each riser and tread, stopping when the blade reaches the junction of the two lines. Finish each cut with a hand saw or jig saw.
Use the first stringer as template to mark the other stringers. Three stringers is the minimum for 32-inch wide stair. Each additional width of up to 16 inches requires an additional stringer.
Measure down down from the top of the deck the distance of 1 riser plus the tread thickness and mark the top tread. Attach the stringers using stringer hangers at this point. Stringer hangers work just like joist hangers except the bottom support is angled to accept the stringer
Deck Railing Posts Installation
Attach railing posts with 1/2-inch carriage bolts. Clamp the posts to the stringers and plumb them from side to side and front to back with a post level or 4-foot level. Drill two holes through the post and stringer for the bolt and insert the bolt from the outside.
|Fasten Rail Posts to Stringers|
Place a washer over the bolt and add a nut. Tighten the nut until the head of the bolt just begins to dimple the wood, but doesn’t cut the wood fibers. Install the stair treads after all the posts are installed. Be sure to leave a 1/8-inch gap between the tread boards.
Building Deck Stair Railing
Lay a 2-by-4 flat on the stair extending from the top post to the bottom post. The board must rest on the end of each stair tread. Use the post as a guide to mark a line at the top and bottom of the stairs. This marks the angle to cut on the railing. On your miter saw, set the table angle to match the angle marked on the 2-by-4. Record this angle on paper for use while cutting balusters and the hand rail.
|Marking Stair Rails for Cutting|
Cut the 2-by-4 on the miter saw at the cut marks. This will be the top board of the railing. Set another 2-by-4 on edge and mark it the same way, except the marks will be across the face of the 2-by-4 instead of the edge. Mark another 2-by-4 the same way and cut both 2-by-4s on the miter saw.
Railings and Balusters
Lay the first 2-by-4 flat on the stairs between the two posts to use as a spacer. Set the second 2-by-4 on edge on top of the first. Make the 2-by-4 flush with the face of the posts on the stair side of the posts. Fasten the 2-by-4 to the railing posts with railing brackets and remove the first 2-by-4 from under the second.
|Stair Railing and Balusters|
Measure up the posts to the railing height minus 1 1/2 inches and mark the posts. Fasten the third 2-by-4 to the posts with railing brackets. Now lay the first 2-by-4 on flat top of the third and fasten it to the posts and the third 2-by-4 with screws. Cut the baluster ends with the angle recorded earlier. Install with finish nails or screws.
The hand rails are not as hard as they might seem and will finish up the DIY deck stair hand rail project. You will make a mitered return on the end of the hand rail and fasten the handrail to the stair railing posts.
Measure the top and bottom posts for the hand railing height and mark them. Measure from the mark on the top post on the side closest to the deck and on the opposite side of the bottom post. On the miter saw, cut a 45-degree angle on the end of the hand rail stock so that the side of the hand rail closest to the railing posts is the short side.
Measure along the long side of the hand rail stock to mark the other cut to the length of the hand rail and cut the hand rail to length on a 45-degree angle. This makes the hand rail shorter on the post-side face and longer on the stair-side face.
Install the cut hand rail on the posts using brass hand rail brackets. Screw the hand rail stand offs to the posts. Set the hand rail on top of the stand offs and have a helper hold it in place. Drill pilot holes for the clamps and screw the clamps over the stand offs.
Measure between the point of the angle cut on the hand rail and the railing post for the mitered return. Measure the hand rail stock for the cut. Set the miter saw table to 45 degrees and cut off the hand rail end. Apply glue to each face of the 45-degree cut on the hand rail and the mitered return. Hold the piece in place and drill two pilot holes for finish nails. Nail the two pieces together with galvanized finish nails.
